730D
Draper Platform
  • Dual-knife drive system is timed
  • Cutterbar is closer to the ground
Make an Enquiry on This Machine
Features
You’ll appreciate the smooth, vibration-free cutting performance the shaft-driven in-line dual knife drive system provides, standard on the 730D.
Expand All
Two available sizes for a 700D factory-installed center feed drum improves feeding of crop into the combine feeder house

The center feed drum is designed for efficient and consistent feeding of the crop into the combine feeder house. Beginning with model year 2020 700D Draper Platforms, customers will have the ability to choose between a 356-mm (14-in.) or 406-mm (16-in.) center feed drum to be factory installed.

Feature benefit:

  • 356-mm (14-in.) or 406-mm (16-in.) diameter factory-installed feed drum significantly improves feeding of the crop
  • Strategic location improves crop handling and capacity, increasing productivity in high-volume crops such as irrigated wheat, barley, or canola
  • Combine performance is improved due to retractable fingers that enable smoother feeding
  • Capacity increase in tough conditions by 20 percent due to an upgraded center feed section slip clutch
Center feed drum Center feed drum
Feed drum retractable auger finger Feed drum retractable auger finger

Functionality:



The feed drum protrudes forward from the draper back sheets, improving the crop handoff from the draper side belts. An increase in slip clutch torque of the center feed drum from 1200 Nm to 1650 Nm allows for increased capacity in tough crop conditions



In some crop conditions, crop can hesitate at the corners of the feed drum but the retractable drum fingers keep the crop moving into the combine.

Takes one person a few minutes to convert draper from field to transport without use of tools

The 730D, 735D, and 740D Draper models can be equipped with an integrated, slow-speed transport system.



John Deere value:

  • Need for a header trailer is eliminated due to dual-front dolly wheel tires with an extendable tongue and two-gauge wheel tires that can carry the complete weight of the draper when in transport

  • Road transport is quicker and easier because one person can convert the draper from field to transport mode in a few minutes without the use of tools

Theory of operation

In field mode, the dual wheels become the left- and right-hand gauge wheels. For transport, the left-hand dual-dolly wheels support one side of the draper frame and the right-hand dual wheels are repositioned to support the right-hand end of the frame.



The transport package includes warning lights, which can be plugged into a seven-way power source for road transport with a 32.2-km/h (20-mph) speed limit for farm equipment transport.

Dual-wheel arm and single-wheel arm assembly Dual-wheel arm and single-wheel arm assembly
Slow-speed transport - rear wheels Slow-speed transport - rear wheels

NOTE: The 730D, 735D, and 740D Drapers are equipped with two ST215/75R14 gauge wheel tires as base equipment and four ST215/75D14 gauge wheels with the low-speed transport option.

Dual-knife drive system is timed
Cutterbar epicyclical gearcase Cutterbar epicyclical gearcase
Knife drive shaft Knife drive shaft

The unique dual-knife drive system is timed, creating the smoothest-possible reciprocating knife-drive system currently in the industry. The positive, reliable shaft-driven dual epicyclical in-line knife drives with built-in driveline protection, provide operators with the strongest knife-drive system.

Double-cut knife system produces a cleaner cut

All John Deere 700D Drapers include a double-cut knife which features a hydraulic tilt that is controlled from inside the cab. All 10.6-m (35-ft) and 12.1-m (40-ft) draper cutterbars have knifeback reinforcement straps to strengthen the knifeback.



Feature benefit:

  • Maximized productivity through longer stroke of knife section provides a faster, cleaner, and smoother cut, which allows operators to harvest at faster ground speeds
  • Productivity is maximized in tough conditions through a reinforced knifeback that strengthens the cutterbar
  • Reduced cost of operation and increased wear life with hardened sickle sections and unique boron treatment
  • Hydraulic tilt optimizes the cutterbar angle for varying conditions, extending the harvest day and providing the lowest-possible cut height
Double-cut cutterbar system Double-cut cutterbar system
Double-cut rock guard Double-cut rock guard
Functionality

The 100-mm (4-in.) cutting action produces a cleaner cut versus the tearing effect of shorter-stroke cutting systems. Knife hold-downs are easily adjusted to help maintain harvesting performance.

Tilt cylinder Tilt cylinder

The cutterbar hydraulic tilt adjusts a full 8 degrees while maintaining excellent visibility to the cutterbar throughout the tilt range. For improved ease of use, the hydro handle can be configured to control the platform tilt.

Reel resume and reverse are features on the 700D Drapers

Reel resume and reverse are features on the 700D Drapers. The combine operator can store two different reel positions with one setting for normal conditions and another for down, tangled, short, or leaning crops.



Feature benefit:

  • Added time savings and convenience with saved reel positions, lowering operator fatigue
  • Increased harvest efficiency through a reel-reverse feature which reverses the reel in conjunction with the center feed drum and belt to back outplugs
Draper drum Draper drum
Draper reel Draper reel
Specifications
Expand All
Key Specs
Cutterbar length
9.3 m
30.5 ft
Knife drive
Base: dual knife
Optional: single
Knife speed
490 cycles/min
Pickup reel operating speeds
6-45 rpm
137.2-cm (54-in.) reel: 5-44 rpm
Draper belts speed control
Hydraulic from cab
Cutterbar
Type
Straight-line knife drive system
Length
9.14 m
30 ft
Knife drive
Base: dual knife
Optional: single
Knife speed
490 cycles/min
Cutterbar tilt
Base: hydraulic, maximum tilt 9 degree (angle)
Base skid shoe height
Pickup Reel
General
Number of slats
Base: six bat poly
Optional: eight bat steel (for forage conditions)
Fingers
Base: nylon
Optional: steel
Diameter
1.067 m
3.5 ft
Height control
Hydraulic
Speed control
Hydraulic
Reel lift
Cylinder stroke: 330 mm
13 in.
Total range: 391.5 mm
15.4 in.
Reel fore and aft
Cylinder stroke: 359 mm
14.1 in.
Total range: 620 mm
24.4 in.
Fore of the cutterbar
Reel resume
Base
Reel reverse
Base
Operating speeds
6-54 rpm
Operating speeds (54-in. reel)
5-44 rpm
Slat Reel
Number of slats
Diameter
Height control
Speed control
Operating speeds
Draper Belts
Width
Rubber coated polyester with V-Guide tracking: 0.7 L
24 oz
Side belts: 1.02 m
3.33 ft
Center belts: 1.4 m
4.583 ft
Center belt not included with SPW configuration
Belt depth
Cleat height
25.4 mm
1 in.
Operating speed
Side belts: variable up to 223 m/min
735 fpm
Center belts: 212 m/min
695 fpm
Center belt not included with SPW configuration
Speed control
Hydraulic from cab
Center belt reverse
Base: center belt not included with SPW configuration
Feed Drum
Diameter
Two factory-installed options: 356 or 406 mm
14 or 16 in.
Feed drum not included with SPW configuration
Feed drum fingers
Heavy-duty and round with breakaway notch and retainer
Diameter: 16 mm
0.625 in.
Number of fingers
18
Auger finger platform
Dual chevron, retracting
Finger reach
152 mm
6 in.
Drum/auger reverse
Base
Operating speed
195 rpm
Center cleanout door
Base
Header Height Sensing
Type
Base: electrohydraulic
Header height sensing on the ground
Base
Header height sensing off the ground
Base
Top Auger
Type
Optional: hydraulic drive
Fingered augers
Size
Dimensions
Platform length
10 m
32.9 ft
Overall operating depth
2.5 m
8.2 ft
Transport width, field position
9.9 m
32.5 ft
Transport width on wheel, less dividers
2.7 m
8.9 ft
Transport length, hitch extended
12.3 m
40.4 ft
Platform
Type
Rigid draper
Approximate weight
Date collected
