In-Field Data Sharing
Data Management
  • Share maps and guidance lines with machines that use Gen 4 displays
  • Can be used with up to six machines
  • Compatible with Gen 4 4600 CommandCenter™ or 4640 Display
  • See coverage and as-applied maps for any machine by toggling between layers


Make an Enquiry on This Machine
Features
With In-Field Data Sharing you can share maps and guidance lines and review the performance of up to six machines working in the same field.
Expand All
Use equipment and people even better with Gen 4 In-Field Data Sharing

Increase the efficiency of your field operations with Gen 4 In-Field Data Sharing by monitoring the operations of up to six tractors, sprayers, nutrient applicators, or combines on one screen.

Equipment can work together at the same time or use maps created earlier by another machine to perform the following:

  • Share as-applied maps and guidance lines between machines used for tillage, planting, and harvesting. Fertilizer and crop protection applications require an additional match on products to make sure the right information is being shared.
  • Improve product placement and eliminate over-application by shutting off planter rows, seeding sections, sprayer nozzles, and fertilizer spreaders or ranks when crossing over areas already covered by another machine.
Layers and legends Layers and legends
  • Monitor the quality of job being performed on other machines.
Three machines sharing coverage Three machines sharing coverage
Sharing as-applied maps Sharing as-applied maps
Ensure that operators are working as efficiently as possible

Sharing maps and vehicle position helps confirm proper performance and help producers manage operations in the field.

  • Zoom out to the field view to make sure the entire field has been covered.
  • View other operators’ as-applied maps to confirm those machines are calibrated and performing properly.
  • View machines’ yield and moisture maps to get a whole field view, to view progress, and to make sure nothing is missed while confirming machine and crop performance.
  • Confirm the position of tractors working with grain carts or in other support functions.
Whole field view Whole field view
Flexible sharing with Work History and Shared Work

Using In-Field Data Sharing’s Join feature, an operator can quickly join geospatially sorted work groups and accept the client, farm, field, and guidance line as well as crop and other documentation entries. The person starting the work group can either send everything or select only what they want the other operators to use.

With the Join feature, starting a field is faster and will result in more consistent usage of guidance lines and documentation data.

Using a streamlined setup process, In-Field Data Sharing matches maps and guidance lines together based on the information selected in the Work Setup screen; the same information is needed to document an operation. Setup items can be sent to the display from Operations Center for selection to make setup even easier.

The information needed depends on the operation:

  • Planting and seeding - client, farm, field, and crop
  • Product application - client, farm, field, and product or tank mix
  • Harvest - client, farm, field, and crop
Work Setup and Work List Work Setup and Work List
Shared Work Shared Work

By joining a work group, you can view and select work history and shared work from a different time if different maps are required to finish an operation. Accessed from the Work List screen, Shared Work displays the data available from the cloud, while Work History displays the information created using the display. For example, if multiple herbicide applications are being made, a previous application can be selected to finish the field.

Searching for other work groups Searching for other work groups
Joining a work group Joining a work group

Shared work data is sent and received in 30-second segments. Including data transfer, a display will typically receive updates to coverage from group members approximately every 30 seconds and updates to group member position approximately every 6 seconds.

NOTE: Data transfer times can vary depending on strength of data connection.
